Circor B4PIC-236AS Imo Pump
Part #: B4PIC-236AS
$0.00
In Stock: 1
| Model Number |
B4PIC-236AS
|
| Nominal Flow Rate | 179.6 GPM (680 LPM) @ 600 PSI, 150 SSU, 3,400 RPM |
| Maximum Speed | 3,600 RPM |
| Max Differential Pressure | 1,000 PSI (68.95 bar) |
| Viscosity Range | 32 to 3,500 SSU (Min. 60 SSU recommended) |
| Operating Temperature | 0°F to 180°F (-18°C to 82°C) |
| Rotation | Clockwise (facing pump shaft) |
| Installation Type | Submersible ("Wet") / Sealless |
| Rotor Housing | Cast Aluminum |
| Power Rotor | Alloy Steel (thread ground) |
| Idler Rotors | Pearlitic Gray Iron or Alloy Steel |
| Bearing | Internal, deep groove ball bearing |
| Shaft Diameter (D) | 1.2598" (32 mm) |
| Net Weight | 59 lbs (26.8 kg) |
| Discharge Connection | 2" NPT |
